Understanding Depth of Field

Derek Smith • 15 December 2020
Depth of field when taking photographs can be a help or a hindrance, dependent on the type of image required. The definition of depth of field can be best described as; “the area of an image that is in sharp focus.”

When taking portraits, a lot of photographers will try and blur the background, limiting the depth of field from the tip of the nose to the back of the head, this is achieved by opening the aperture on the lens to one of the lowest f numbers, only by experimenting with the camera / lens combination will a photographer be able to know what works best for them. With my previous full frame Sony, and 85mm lens f/1.8 gave a far shallower depth of field, and so I favoured an aperture setting of f/2 to f/4.

This image of Rachel from a recent photoshoot with my micro four thirds system camera using a 25mm prime lens (50mm FF) has a field of view of 38 degrees, and at f/1.8 the depth of field is 0.06m, enough to keep the nose, and both eyes sharp, with the ears just beginning to soften, the background is suitably blurred, keeping the emphasis on the face.

In portraiture the focus point will usually be set on the eyes, and I would typically use f/1.8 – f/2.8 aperture in an outdoor situation. Indoors, or in a studio depending on the lighting and distance from the subject, an aperture of f1.8 – f/8 could be employed to give the correct depth of field, and exposure.

Interestingly we find that the depth of field will double for every two stops that the lens aperture is stopped down, hence with the micro four thirds 25mm prime lens:

At f/2            depth of field =        0.010m.
At f/2.8        depth of field =        0.015m.
At f/4            depth of field =        0.02m.
At f/5.6        depth of field =        0.03m.
At f/8           depth of field =        0.04m.

The images of the TV remote show the quite dramatic difference with the first image taken at f/2, and the second image taken at f/8.

In shooting landscapes, the photographer will be looking to have a greater depth of field, ensuring that the scene is sharp from the foreground to the furthest distance away, use a mid-range aperture usually f/5.6 – f/11 depending on the sensor size, and lens used, because most lenses are sharper in the mid-range, often called the "sweet spot".  Another tip is to focus a third of the way into the scene, this is a rough rule of thumb to ensure sharpness throughout the scene. In this example image of a tree in a glade, my zoom lens was set at a focal length of 18mm (36mm FF), and aperture of f/5.6, focusing on the tree, which is about a third of the way into the scene, gave a depth of field from 2.06m to infinity ensuring the whole scene was pin sharp throughout.

For shooting macro insect photography, the photographer is often tempted to push the front element of the lens as close as possible to the creature, but the closer the lens is to a subject the shallower the depth of field, so move back, it is far easier to crop into an image than try to rescue an unsharp image, and we have all been there!!

So, this morning I would encourage you to get the camera out, dust it off, and try different camera, and lens combinations, experiment with different apertures, and find what suits you in the various scenarios.

Have fun, stay safe, enjoy your hobby.
